      Bernoulli Apparatus

      Bernoulli Apparatus
      Bernoulli Apparatus
      Send Inquiry
      Product Code : FM001
      Brand Name : MECHMATICS ENGINEERING PVT. LTD
      Product Description

      BERNOULLI'S APPARATUS



      Bernoulli's principle named after the Dutch-Swiss mathematician Daniel Bernoulli is one of the most widely used theorem in the field of fluid dynamics. It application ranges from design of  Flow meters, Aircrafts, Carburetors etc.

      The apparatus consists of converging diverging circular test section. Static Pressure tapings are provided across the length of the section and velocity head is measured with the help of measuring tank. Inlet tank is made of Perspex and discharge valve allows reading for various flow rates.



      Specifications:

      1.Converging Diverging Perspex Test Section: 200 mm
      2.No. of Pressure Tappings: 7 Nos.
      3.Sump tank capacity : 75 litres MOC: SS-304 with Matt Buffing
      4.Volumetric tank capacity : 40 litres. MOC: SS-304 with Matt Buffing
      5.Pump : Monoblock type; 0.5 HP
      6.Piping with necessary Valves and Fittings
      7.Digital Stop Watch with 1/10 second Accuracy
      8.Detailed Technical Manual and On-site Training
