    Thermal Conductivity of Insulation Powder

    Thermal Conductivity of Insulation Powder
    Thermal Conductivity of Insulation Powder
    Product Code : HMT-008
    Product Description

    Thermal Conductivity of Insulation Powder

    Determination of thermal conductivity is important as it is the measure of how quickly heat passes through given material. Insulating powders are widely used in heat insulation applications

    The apparatus consists of two thin walled concentric copper spheres. The inner sphere houses the heating coil. The insulating powder is packed between the two shells. The power supply to the heating coil is adjustable. Thermocouples are embedded on the outer surface of the inner sphere and inner of the outer shell.

    Technical Specifications:

    Specifications

    Control Panel

    Heater

    Thermocouples

    Sphere: ID: 75 mm

    Digital Voltmeter (0-230V)

    400 Watt

    K-type (Cr.Al)

    OD 150 mm

    Digital Ammeter (0-2 Amps)

    Spherical Type

    6 Nos.

    MOC: Copper

    (Optional Wattmeter: 400W)

    Dimmer Controller

    Multi-Channel Temp. Indicator

    -

    Toggle ON/OFF

    -

    -
